Q235 Carbon Steel Plate

Q235 Carbon Steel Plate

Carbon steel plate is a kind of high-quality steel with high strength, good plasticity and toughness. It is widely used in construction, machinery, ships and other fields. Its surface is smooth, easy to process and weld, has excellent corrosion resistance, and can maintain product stability and safety for a long time. In addition, carbon steel plates also have good wear resistance, impact resistance and high temperature resistance, providing reliable protection for various complex working conditions. Choosing our carbon steel plates is a guarantee of quality and safety.

- Product Description

Product Name

A36/Q235/S235JR Carbon Steel Plate

Production Process

Hot Rolling, Cold Rolling

Material Standards

AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc.

Width

100mm-3000mm

Length

1m-12m, or Customized Size

Thickness

0.1mm-400mm

Delivery Conditions

Rolling, Annealing, Quenching, Tempered or Standard

Surface Process

Ordinary, Wire Drawing, Laminated Film

Chemical Composition

C

Cu

Fe

Mn

P

Si

S

0.25~0.290

0.20

98.0

1.03

0.040

0.280

0.050

Mechanical Properties

A36

Limit Tensile Strength

Tensile Strength,

Yield Strength

Elongation at Break

(Unit: 200mm)

Elongation at Break

(Unit: 50mm)

Modulus of Elasticity

Bulk Modulus

(Typical for Steel)

Poisson's Ratio

Shear Modulus

Metric

400~550 MPa

250 MPa

20.0%

23.0 %

200 GPa

140 GPa

0.260

79.3 GPa

Imperial

58000~79800 psi

36300 psi

20.0%

23.0 %

29000 ksi

20300 ksi

0.260

11500 ksi

Physical Performance

Physical Performance

Metric

Imperial

Density

7.85 g/cm3

0.284 lb/in3

Scope of Application

Bolted, riveted or welded structures for bridges, buildings and oil drilling rigs.
Used for forming storage tanks, silos, bearing plates, fixtures, rings, templates, fixtures, sprockets, cams, gears, bottom plates, forgings, decoration engineering, piles, brackets, automobiles and agricultural equipment, frames, mechanical parts, etc.

Equivalent Material

National Standard GB

European Standard EN

American Standard ASTM

German Standard DIN, WNr

Japanese Standard JIS

French Standard AFNOR

British Standard BS

Canada HG

Q235B

S235JR

A283C

St37-2

SM400A

E24-2

40A/40B

230G

Italy UNI

India IS

Switzerland SS

Australia ONORM

Norway NS

Spain UNE

International Standards ISO

Portugal NP

Fe360B

IS2062

1311/1312

RSt360B

NS12123

AE235B-FN

E235B / Fe360B

FE360-B
